📘 Overview
The Morn Continuous Wave (CW) Fiber Laser Cleaning Machine is built for fast, efficient, non-contact surface cleaning. Perfect for removing rust, paint, coatings, grease, and rust scale from large and complex metal and non-metal surfaces without damaging the base material. With selectable powers (1000W to 3000W), adjustable scanning width, and accurate spot control, this system delivers high throughput and stable performance for industrial cleaning needs.
⚙️ Specifications (Model Variants)
| Model |
Laser Power |
Scan Width |
Spot Diameter |
Wavelength |
Adjustment Range |
Cooling / Head |
| MT‑CL1000 |
1000W |
≤ 250 mm |
0.08 mm |
~1080 nm |
10‑100% |
Customizable fiber length, manual or scanner head |
| MT‑CL1500 |
1500W |
≤ 250 mm |
0.08 mm |
~1080 nm |
10‑100% |
Same options |
| MT‑CL2000 |
2000W |
≤ 250 mm |
0.08 mm |
~1080 nm |
10‑100% |
Same options |
| MT‑CL3000 |
3000W |
≤ 250 mm |
0.08 mm |
~1080 nm |
10‑100% |
Same options |
Additional details:
🧰 Key Features
-
Non‑contact cleaning — cleans surfaces without physical abrasion or chemicals
-
Large‑area capability — cleaning width up to ~250 mm and large scan range for bulk cleaning tasks
-
High precision — 0.08 mm spot size enables fine control, minimal substrate damage
-
Variable power control — full range from 10% to 100%, so operator can dial in the intensity needed for different coatings or rust levels
-
Flexible deployment — handheld cleaning head or scanner head manipulateable for different geometries, even integration with robotic arms for automated cleaning
✅ Ideal Applications
-
Rust & corrosion removal from large steel structures, pipelines, frames
-
Paint / coating stripping for refurbishing or repainting
-
Surface preparation before welding or coating
-
Cleaning of molds, dies, machinery components, or surfaces with delicate or precise finishes
-
Outdoor or on‑site cleaning where chemical or abrasive methods are impractical or unacceptable
📦 What’s Included / Considerations
-
Chassis with laser source (chosen MT‑CL power variant)
-
Cleaning head (handheld or scanner type)
-
Control panel with power adjustment and monitoring
-
Fiber optic cable of selectable length
-
Safety accessories (protective lenses, gloves, etc.)
-
Cooling system as required
🔍 Critical Notes
-
Actual cleaning width, speed, and effectiveness depend on material type, coating/thickness, surface conditions (rust buildup, paint layers), and operator settings.
-
If using handheld head, user fatigue and safety gear are important.
-
Maintenance includes cleaning optics, alignment, and ensuring cooling is adequate.
📘 Support & Resources
-
Warranty: As per Morn’s standard terms (confirm based on model)
-
Documentation: Setup guides, usage & cleaning tips, safety guidelines
-
Application support: Morn offers sample cleaning tests and demos for complex scenarios
