Overview
The 22 IDEX v3 is a precision‑engineered, industrial‑grade 3D printer built for high‑temperature materials and demanding applications. With dual independent extruders reaching up to 500 °C, an actively heated chamber, and a self‑leveling heated bed, it offers unmatched control and performance for professionals working with advanced polymers.
Key Features
-
Dual 500 °C Extruders – Each hotend reaches ultra‑high temperatures for printing with engineering‑grade materials and dissolvable supports.
-
Actively Heated Chamber + Self‑Leveling Bed – Maintains consistent temperatures for warp‑resistant printing and ensures flat, even layers.
-
Robust Mechanical Framework – Steel chassis, linear rails, and reinforced belts provide rock‑solid precision for consistent print quality.
-
Smart Control & Calibration – Features auto‑leveling, XY alignment, filament drying, and remote monitoring for automated, hands‑off printing.
Specifications
| Specification |
Detail |
| Category |
Industrial Dual‑Extrusion High‑Temp 3D Printer |
| Model / SKU # |
22 IDEX v3 |
| Retail Price (approx.) |
$14,900.00 |
| Build Volume |
350 × 350 × 450 mm (13.7 × 13.7 × 17.7 in) |
| Build Plate Temp. |
Up to 200 °C |
| Chamber Temp. |
Actively heated to ~100 °C |
| Extruder Temp. |
Up to 500 °C (both hotends) |
| Mechanics |
Steel frame, linear rails, quad motors, triple Z‑axis |
| Leveling System |
Fully automatic with mechanical + mesh leveling |
| Firmware / Interface |
Duet 3 board, Ethernet, WiFi, web control panel |
| Dimensions / Weight |
535 × 568 × 739 mm; ~200 lbs (90.7 kg) |
Compatibility
-
Software: Works with major slicers like PrusaSlicer, Simplify3D, OrcaSlicer
-
File Formats: STL, OBJ, and G‑code
-
Material Range: Supports PEEK, PEKK, ULTEM™, Nylon, PC, Carbon Fiber, and more
Warranty
-
Manufacturer Warranty: 1-Year Limited
-
Support Coverage: Includes documentation, tutorial videos, and live support options
Customer Resources
📄 Brochure
📄 Support Center
▶️ Setup / Unboxing
▶️ Maintenance & Usage Videos: Covers slicing tips, firmware, and material calibration
